CATALOGUE 2017

About ANTTRON :

ANTTRON is a company with headquarters in Torhout, Belgium. In this catalogue you will find all products that are conceived, developed and produced in house

using latest ‘state-of-the art’ development, production and testing equipment.

At ANTTRON we strive to present products which excel in quality, originality and userfriendlyness. This ‘straight-forward and no nonsense policy’ has proven its

benefits over the last 50 years that ANTTRON products have been on the international market.

We hope you enjoy our latest developments you can find in this catalogue.

Christoff DEVLOO

General manager and owner.

DTVRACK : modular headend

page 4-9

COMPACT HEADENDS - TRM series

page 10-11

HD ENCODER MODULATOR

page 12-15

A/V ENCODER MODULATOR

page 16-17

Masthead amplifiers

page 18

LTE block filters

page 19

Power supplies for mastheadamplifier

page 19

Indoor distribution amplifier

page 20

Multiband and CATV amplifier

page 21

Satellite accessories

page 22-23

Multiswitches

page 24-26

DTVRACK OVERVIEW

TVAV2 : This twin Audio Video encoder allows

o CVBS inputs to be encoded into MPEG2 for-

at and . They are combined into one transport

ream.

TVHD4 : This module allows to encode 4 HD

urces via HDMI in H264/AAC-MPEG1-L2 up to

solutions of 1080p.

DTVIPi : This module allows to convert incoming IP

streams to a transport stream

IRM : Intelligent remuxing

DTVAV2

DTVHD4

DTVRR4

.ts USB

OUT

ts out

DTVRR6 and DTVRR8: A dual or triple in-

DTVRack : the most flexible headend

put universal module allowing reception of

DTVRack is a unique concept when we talk about headends. Based

DVBT/T2/C/S/S2 signals, making it possible

on a 19 inch rack with a backplane where transport streams can be

to combine ,terrestrial,satellite and cable

OUT

connected with eachother, it forms the basis for a flexible headend.

programs to prepare them for remodulation

and/or decryption.

Besides the powersupply in the rack, which also acts as a communi-

cation hub to the outside world (PC or web), a collection of different

However, things can only get better. All modules DTVAV2,DTVHD4,

modules makes the headend complete.

DTVRRx and DTVIPi modules have an extra input. This extra input

The unendless possible combinations of these modules give you for

collects a transport stream from the backplane in the rack and multi-

each situation the most ideal solution.

plexes the transport stream with the transport stream coming from

DTVRR2, DTVRR9 and DTVRR10 : A dual satellite input allowing re-

the module itself.

Input modules :

ception of DVBS/S2 and DVB/S2X multistream signals (DTVRR10

We call it ‘IRM’ - Intelligent ReMuxing.

On the source side, we distinct ten different modules.

only).

As a result, you can collect programs from many different satellite

DTVRR4 and DTVRR7. These powerful mod-

DTVRR9 allows at the same time

, terrestrial and cable frequencies, together with audio video pro-

ules have two (DTVRR4) or three (DTVRR7)

H264 encoding of a HDMI source or

grams, to form your own transport stream.

satellite inputs. The transport streams com-

addition of a .ts file over USB key.

ing from these satellite inputs can be multi-

The example above shows for instance how a transport stream

plexed together to form one unique transport

with two audio/video inputs and 4 HDMI inputs together with sat-

stream.

ellite programs from 4 different frequencies can be combined to

form one transport stream

DTVRACK OVERVIEW

Digital signage : creating your own content

how your transport stream you created will be modulated by just

selecting the right modulator(s).

Imagine, how interesting it can

Decryption

be to create your own content

Also an IP streamer (DTVIP) can be put in the rack in order to out-

and distribute it over your DVBT

Decrypting programs is easily solved using the

put your multiplex in RJ45 and provide IPTV.

of DVBC network !

modules DTVCI1 or DTVCI2. These modules can

be placed after the receiving side, allowing the

With the DTVRR4, DTVRR6 and

decryption of services using the right CAM and

DTVIface : your headend at a glance

DTVRR9 module, also this is

CARD.

possible. Each module has an extra USB input. A USB key can be

Do you know that DTVCI1, DTVCI2 modules can

connected where your content under the form of .ts files can be

be put in cascade ?

stored. According to a time schedule you define, movies/ presenta-

So, if your card or CAM has restrictions on the

tions and so on, can be broadcasted as a replacement of an existing

number of programs to be decrypted, just add

program or as a standalone program. For DTVRR9, you have the

another DTVCI1 (max.4) or DTVCI2 module (max.

choise to select wether the USB input or an HDMI input to broad-

2) and extent the number of programs to be

cast your info channel or other application.

decrypted !!

All kinds of informations, can in this way be distributed in hotels,

appartment building, senior homes or whatever application you

have in mind.

Also the content available on the USB stick can be changed over the

web. Just upload your new .ts file from your computer at home or

office to your DTVRack. In a matter of minutes new information can

Choice of modulation DVBT ,DVBC or IP streamer

be broadcasted over the DVB-T / DVB-C network of your customer.

Web control

Modules DTVDM2F and DTVDM3F are twin respectively triple DVBT

modulators, with the great advantage that the output channels

Your completed headend is programmed using the software pro-

Satellite frequencies are changing continuously, or your customer

can be freely chosen over the entire VHF (ch 5-12) and UHF (ch 21-

gram DTVIface.

wants some other programs in his network, or he wants the con-

69) band. This allows optimal usage of free channels in the DVBT

tent of its internal channel to be changed.

spectrum.

This software excels by ease of installation, and simple and intuitive

Do not worry ! Instead of going on site to perform the necessary

Modules DTVDM3, DTVDM4, are respectively triple or quad DVBT,

GUI. It allows direct programmation of the complete headend with

modifications, just hook up the DTVPCU (power supply) module in

DVBC modulators (adjacent). These modulators can be configured

possibility to save configurations and load them again on other

DTVRack to the web.

in the field to act as DVBT or DVBC modulator. You finally define

DTVRacks. Both control over USB or over your local network (using

From your office or home, take full control over your headend and

RJ45 connection) are possible.

adjust programming in a couple of minutes.

DTVIface allows to produce easy to read .html reports of your

configuration.

DTVRACK : the input modules

DTVRR4/DTVRR7

SAT inputs (x2)

Frequency

950-2150 MHz

.ts USB

Input level

-65 dBm à -25 dBm

• Module for the reception of DVBS/S2 satellite signals

Insertion loss

< 2.5 dB

• Two (DTVRR4) or three (DTVRR7) inputs with integrated multiplexer

LNB supply

13/18V - Tone - DiSEqC (300mA each input)

DVB-S

Modulation - symbol rate

QPSK - 1….45 MSps

• The programs of the two satellite inputs can be ‘remuxed’ (mixed) with pro-

OUT

Code rate (Viterbi)

1/2, 2/3, 3/4, 5/6, 7/8

grams coming from a preceding DTVRRx, DTVHD4, DTVAV2, DTVIPi

ts out

DVB-S2

Modulation - symbol rate

QPSK/8PSK - 1….45 MSps

Code Rate (LDPC)

QPSK = 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10

• Host USB input to create your own program. The program has to be available

8PSK = 3/5, 2/3, 3/, 5/6, 8/9,9/10

in .ts format. (DTVRR4 only)

OUT

Current consumption @5V

600 mA

EAN code

DTVRR4

5420037699315

•

13/18 V - 22 kHz - DiSEqC control for each input

DTVRR7

5420037699568

ts from previous

Terrestrial/cable/SAT

Frequency

110-862 MHz + 950-2150 MHz

(x2 or x3)

Input level (DVBT/T2/C)

-75 dBm to -20 dBm DVBT/T2 - -62 dBm to -20 dBm DVBC

Input level (SAT)

-65 dBm à -25 dBm

DTVRR6/DTVRR8

.ts USB

LNB supply

13/18V - Tone - DiSEqC (300mA each input)

DVB-S

Modulation - symbol rate

QPSK - 1….45 MSps

• Module for the reception of DVBT/T2/C or DVBS/S2 signals

Code rate (Viterbi)

1/2, 2/3, 3/4, 5/6, 7/8

• PLP support in DVB-T2 mode

DVB-S2

Modulation - symbol rate

QPSK/8PSK - 1….45 MSps

Code Rate (LDPC)

QPSK = 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10

• Two (DTVRR6) or three (DTVRR8) inputs with integrated multiplexer

ts out

8PSK = 3/5, 2/3, 3/, 5/6, 8/9,9/10

• The programs of the two inputs can be ‘remuxed’ (mixed) with programs com-

DVB-T2 : EN 302 755

Modulation - FFT mode

QPSK, 16QAM, 64 QAM, 256 QAM - 1K,2K,4K,8K,16K,32K

Channel bandwidth - Code Rate

6,7,8 MHz - 1/2, 3/8, 2/3, 3/4, 4/5, 5/6

ing from a preceding DTVRRx, DTVHD4, DTVAV2, DTVIPi (cascadable)

Guard Interval

1/4, 5/32, 1/8, 5/64, 1/16, 1/32,1/64,1/128

• Host USB input to create your own program. The program has to be available

DVB-T : EN 300 744

Modulation - FFT mode

QPSK, 16QAM, 64QAM - 2K,8K

ts from previous

Channel bandwidth - Code rate

6,7,8 MHz - 1/2, 2/3, 3/4, 5/6, 7/8

in .ts format. (DTVRR6 only)

Guard Interval

1/4, 1/8, 1/16, 1/32

•

13/18 V - 22 kHz - DiSEqC control for each SAT input

DVB-C : EN 300 429

Modulation

16, 32, 64, 128, 256 QAM

Channel bandwidth -Symbol Rate

6,7,8 MHz - 0.2 - 7.2 Msps

•

Current consumption @5V

600 mA

EAN code

DTVRR6

5420037699551

DTVRR8

5420037699599

DTVRR2/DTVRR9

SAT inputs (x2)

Frequency

950-2150 MHz

Input level

-65 dBm à -25 dBm

• Module for the reception of DVBS/S2 satellite signals

.ts USB

Insertion loss

< 2.5 dB

• Two inputs with integrated multiplexer

LNB supply

13/18V - Tone - DiSEqC (300mA each input)

DVB-S

Modulation - symbol rate

QPSK - 1….45 MSps

• The programs of the satellite inputs can be ‘remuxed’ (mixed) with programs

Code rate (Viterbi)

1/2, 2/3, 3/4, 5/6, 7/8

OUT

ts out

coming from a preceding DTVRRx, DTVHD4, DTVAV2, DTVIPi (cascadable)

DVB-S2

Modulation - symbol rate

QPSK/8PSK - 1….45 MSps

Code Rate (LDPC)

QPSK = 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10

•

13/18 V - 22 kHz - DiSEqC control for each input

8PSK = 3/5, 2/3, 3/, 5/6, 8/9,9/10

OUT

• DTVRR9 has an HDMI or .ts (via USB) input. This allows insertion of the HDMI

HDMI

Video / bitrate

H264 - bitrate 5-15 Mb/s

Audio / bitrate

AAC-LC or MPEG1-L2 - bitrate 128-384 Kb/s

source or info channel (via USB) in the .ts output.

ts from previous

Current consumption @5V

600 mA

EAN code

DTVRR2

5420037699629

DTVRR9

5420037699636

DTVRACK : the input modules

SAT inputs (x2)

Frequency

950-2150 MHz

DTVRR10

Input level

-69 dBm à -29 dBm

LNB supply

13/18V - Tone - DiSEqC (300mA each input)

• Module for the reception of DVBS/S2/S2X - multistream satellite signals

DVB-S

Modulation - symbol rate

QPSK - 1….45 MSps

Code rate (Viterbi)

1/2, 2/3, 3/4, 5/6, 7/8

• Two inputs with integrated multiplexer

DVB-S2

Modulation - symbol rate

QPSK/8PSK - 1….45 MSps

• The programs of the two satellite inputs can be ‘remuxed’ (mixed) with pro-

Code Rate (LDPC)

QPSK = 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10

grams coming from a preceding DTVRRx, DTVHD4, DTVAV2, DTVIPi

8PSK = 3/5, 2/3, 3/, 5/6, 8/9,9/10

DVB-S2X

Multistream

CCM, ACM, VCM, Multi Input Stream, 16APSK,32APSK,Ge-

•

13/18 V - 22 kHz - DiSEqC control for each input

neric Stream Mode

Current consumption @5V

600 mA

EAN code

DTVRR10

5420037699643

Input (x2)

Video - Input level - impedance

CVBS - 0.7

1.4Vpp - 75 Ohms

DTVAV2

Audio

0.5...2.5 Vpp

Compression

Video / bitrate

MPEG2 / 4

12 Mb/s

• Module for MPEG2 encoding of audio/video sources

Audio / bitrate

MPEG1, Layer II / 128, 192, 256, 320, 384 kb/s

Current consumption @5V

800 mA

• Two inputs with integrated remuxer

EAN code

DTVAV2

5420037699407

• The digitised audio/video sources can be remuxed with programs

ts out

coming from a preceding DTVAV2 module. In this way a multisource

(2-4-6-8 etc.) can be realised

ts from previous

Input (x4)

HDMI

DTVHD4

Compression

Video / bitrate

H264 - bitrate 5-15 Mb/s

Audio / bitrate

AAC-LC or MPEG1-L2 - bitrate 128-384 Kb/s

Current consumption @5V

2000 mA

EAN code

DTVHD4

5420037699445

• Module for MPEG4 (H.264) encoding of HDMI sources

ts out

• Four inputs with integrated remuxer

• Resolutions up to 1080p (x4)

ts from previous

DTVIPi

Input

Parallel T.S.

Up to 100Mb/s

Standard

IEEE.802.3 10/100 base T

Protocols

unicast/multicast I.P. over UDP/RTP

• The DTV-IPi module purpose is to capture SPTS/MPTS services from several

Capacity

Up to 15 simultaneous SPTS and/or MPTS channels (up

ethernet unicast and/or multicast ports, multiplex them in a single TS that

to 32 activable services by channel with a total max

number of 512 PIDs)

is provided to the DTVRack backplane. The extracted services can then be

Connector

Ethernet

RJ45

reorganized in multiple TS and modulated in DVB-C, DVB-T or even streamed

EAN code

DTVIPi

5420037699582

again in IP using various output modules.

DTVRACK : racks / CI slots / accessories

DTVRack

• Basic rack to incorporate other modules from the DTVRack system

• Maximum 11 modules can be put into one Rack

• USB for connection between PC and Rack for control

• Ethernet connection for web control or control over local network

• Wall mount or mounting possible in a 19 inch rack (height 3U)

• Powersupply : 125 Watt

EAN code

5420037699308

CMIRack

• Semi rack to incorporate other modules from the DTVRack system

• Maximum 5 modules can be put into one CMIRack

• USB for connection between PC and Rack for control

• Ethernet connection for web control or control over local network

• Wall mount

• Powersupply : 125 Watt

EAN code

5420037699483

DTVCI1

DTVCP

• CI module

• Coverplate to close unused slots in a rack.

• Allows the decryption of multiple channels (quantity depending on CARD and CAM used)

EAN code

5420037699384

•

4 modules can be put in cascade to augment the number of programs to be decrypted

EAN code

5420037699322

DTVCI2

DTVCC

• Dual CI module (accepts two CAM modules)

• CAM cover (for use with DTVCI1, DTVCI2)

• Allows the decryption of multiple channels (quantity depending on CARD and CAM used)

EAN code

5420037699384

•

2 modules can be put in cascade to augment the number of programs to be decrypted

EAN code

5420037699476

DTVRACK : the output modules

Output level

> 95 dBµV (adjustable in DTVIface)

DTVDM2F / DTVDM3F : dual or triple DVBT modulator

Bypass insertion loss

< 2 dB

Output frequency

170-230 MHz + 470-862 MHz

Constellation

QPSK/16QAM/64QAM

• Dual or Triple DVBT modulator module for DTVRack.

FEC

1/2, 2/3, 3/4, 5/6, 7/8

Guard interval

1/4, 1/8, 1/16, 1/32

• The output channel/frequency of each modulator (2 or 3) can be freely chosen in the

Mode - MER

2K/8K - > 31 dB

VHF-UHF band.

DVB Processing

TsID, NIT version, ONID, NID, Network Name, LCN, HDLCN

Current consumption @5V

400 mA

• Modulation parameters and output level can be individually set.

EAN code

DTVDM2F : 5420037699612

DTVDM3F : 5420037699605

DTVDM3 : triple DVBT/ quad DVBC modulator

• Triple DVBT/ quad DVBC modulator module for DTVRack

• Three/four adjacent channels

Output level

> 95 dBµV (adjustable in DTVIface)

Bypass insertion loss

< 2 dB

• Channels are only active if services (programs) added to the channel (single channel pos-

DVBT mode

Output frequency

170-230 MHz + 470-862 MHz

sible)

Constellation

QPSK/16QAM/64QAM

• Can be reconfigured in the field to DVBC or DVBT modulator

FEC

1/2, 2/3, 3/4, 5/6, 7/8

Guard interval

1/4, 1/8, 1/16, 1/32

Mode - MER

2K - > 35 dB

DVBC mode

Output frequency

50-862 MHz

Constellation

16,32,64,128,256 QAM (EN 300 429)

DTVDM4 : quad DVBT/DVBC modulator

Symbol Rate

4 - 6.96 Mb/s

MER

> 39 dB

• quad DVBT/DVBC modulator module for DTVRack

DVB Processing

TsID, NIT version, ONID, NID, Network Name, LCN, HDLCN

Current consumption @5V

DTVDM3 = 1000 mA

• Four adjacent channels

DTVDM4 = 1400 mA

• Channels are only active if services (programs) added to the channel (single channel,dual

EAN code

DTVDM3 : 5420037699346

DTVDM4 : 5420037699353

or triple operation possible)

• Can be reconfigured in the field to DVBC or DVBT modulator

DTVIP : IP to DVB streamer

• Standard : RJ45 ethernet 10/100 base T

• Rate : up to 100 Mbps

• Number of programmes at output : up to 16 SPTS (single program transport stream) or 16 MPTS (multiple programs transport stream)

• Transmission protocol : UDP/RTP (TTL & QoS configurable) - SDP/SAP to ease automatic selection of programmes on the settop box

• IP configuration : fixed or DHCP

• IP addressing : multicast - unicast

• DVB : PID filtering , SI/PSI analysis - PAT/PMT table regeneration

Current consumption @5V

400 mA

EAN code

5420037699452

COMPACT HEADENDS - TRM series

Based on the modular rack system DTVRack, we arranged some combinations of modules in one closed housing, compact

TRM23

headends.

This allows your customers to select a handy compact product for a specific function.

.ts USB

OUT

The combinations are as follows :

TRM23 : combines a module DTVRR4 with a modulator DTVDM3, allowing two satellite transponders to be transmodulated

in DVBT (3 output channels) or DVBC (4 output channels).

OUT

TRM44 : combines 2 modules DTVRR4 with a modulator DTVDM4, allowing four satellite transponders to be transmodulated

in DVBT or DVBC (4 output channels).

TRM54 : combines module DTVRR2 and DTVRR7 with a modulator DTVDM4, allowing five satellite transponders to be trans-

modulated in DVBT or DVBC (4 output channels).

OUT

TRM64 : combines module DTVRR9 and DTVRR7 with a modulator DTVDM4, allowing five satellite transponders to be trans-

Schematics TRM23

modulated in DVBT or DVBC (4 output channels). To this you can add a HDMI source or .ts file over USB.

TRM54

TRM24CI : combines one pair of modules DTVRR4 and DTVCI1 with a modulator DTVDM4, allowing the decryption of two

.ts USB

OUT

satellite transponders to be transmodulated in DVBT or DVBC (4 output channels)

TRM342CI : combines one pair of modules DTVRR7 and DTVCI2 with a modulator DTVDM4, allowing the decryption of three

satellite transponders over 2 CAM slots to be transmodulated in DVBT or DVBC (4 output channels)

TRM46CI : this is a ‘modified’ CMiRack which contains 2 groups of the combination DTVRR4-DTVCI1-DTVDM3, thus offering

OUT

4 sat inputs and 6 (8) DVBT (DVBC) channels with the possibility to decrypt the received programs.

Off course, all these products benefice from the same

advantages as the DTVRack concept :

OUT

remuxing / web control / .ts file distribution.

Schematics TRM44

TRM54

TRM64

DVB-C/DVB-T selectable in the field

USB and ethernet for local and

remote (web)control

By pressing the T<->C button in DTVIface, the DVBC

modulator can be converted in DVBT or vice versa.

COMPACT HEADENDS - TRM series

TRM24CI

.ts USB

OUT

Technical specifications

SAT inputs

Frequency

950-2150 MHz

(x2 - TRM23/TRM24CI)

(x4 - TRM44/TRM46CI)

OUT

(x5 - TRM54/TRM64)

Input level

-65 dBm à -25 dBm

Insertion loss

< 2.5 dB

LNB supply

13/18V - Tone - DiSEqC (300mA each input)

Demodulator/decoder

DVB-S

Modulation - symbol rate

QPSK - 1….45 MSps

Code rate (Viterbi)

1/2, 2/3, 3/4, 5/6, 7/8

OUT

DVB-S2

Modulation - symbol rate

QPSK/8PSK - 1….45 MSps

DVB-S2

Code Rate (LDPC)

QPSK = 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5,

Schematics TRM24CI

5/6, 8/9, 9/10

8PSK = 3/5, 2/3, 3/, 5/6, 8/9,9/10

DVBT output

Maximum output

> 95 dBµV

TRM342CI

(3 adjacent channels TRM23)

Attenuation

1 - 20dB (using DTVIface)

(4 adjacent channels TRM24CI/TRM44/

Insertion loss

< 2 dB

OUT

TRM54/TRM64/TRM342CI)

(2 x 3 adjacent channels TRM46CI)

Output frequency

170-230 MHz + 470-862 MHz

OUT

Constellation

QPSK/16QAM/64QAM

FEC

1/2, 2/3, 3/4, 5/6, 7/8

Guard interval

1/4, 1/8, 1/16, 1/32

Mode - MER

2K - 35 dB

DVBC output

Maximum output

> 95 dBµV

OUT

(4 adjac. channels TRM23, TRM24CI,

Attenuation

1 - 20dB (using DTVIface)

TRM44, TRM54, TRM64, TRM342CI)

Insertion loss

< 2 dB

(2 x 4 adjac. channels TRM46CI)

Output frequency

50-862 MHz

Constellation

16,32,64,128,256 QAM (EN 300 429)

OUT

Symbol Rate

4 - 6.96 Mb/s

MER

> 39 dB

DVB Processing

TsID, NIT version, ONID, NID, Network Name,

Schematics TRM342CI

SID, LCN, HDLCN

Power

Input

100-240 VAC / 50-60Hz / 1A

Dimensions

Length x Height

181mm x 103 mm

Width

TRM23 = 100mm

TRM24CI /TRM44/TRM54/TRM64/TRM342CI

TRM46CI

= 130mm

TRM46CI = 271 mm

Weight

TRM23 = 1.5 kg / TRM24CI = 1.6 kg

TRM44/54/64/342CI = 1.7 kg / TRM46CI = 3.2 kg

.ts USB

OUT

.ts USB

OUT

EAN code

TRM23

5420037699537

TRM24CI

5420037699544

TRM44

5420037699520

TRM54

5420037699650

OUT

TRM64

5420037699667

TRM342CI

5420037699520

TRM46CI

5420037699575

OUT

Schematics TRM46CI

HD ENCODER/MODULATOR

Technical specifications - TM160HD/TM190HD

TM160HD

The TM160HD is a HD encoder. The video and audio are taken from

HDMI.

Video input

Input

HDMI

Resolution modes

480p -576p -720p - 1080i -1080p

After compressing the video into H264 and audio in AAC or

Compression

H.264 - bitrate 5-15 Mb/s

MPEG1-L2, the output signal is available in DVBT format.

Audio input

Input

HDMI

Sample Rate

HDMI (32kHz / 44.1 kHz / 48 kHz)

Standalone configuration is made easy through 3 tact switches.

Compression

AAC-LC or MPEG1-L2 - bitrate 128-384 Kb/s

Extended configuration of the TM160HD is possible using the spe-

DVB Processing

Table insertion

PAT, PMT, SDT, NIT

cial software TMHDIface.

Configuration

Channel/network name, SID, LCN, TSID, ONID, NID, audio, video PIDs…

DVB-T output

Output frequency / level

170-230 MHz + 470-862 MHz / > 85 dBµV

Constellation - FEC

QPSK/16QAM/64QAM - 1/2, 2/3, 3/4, 5/6, 7/8

Guard interval

1/4, 1/8, 1/16, 1/32

Mode - MER

2K/8K - 31 dB

Power

DC 2.1 mm connector

+5V

Consumption

6 Watts

• video : H264

Dimensions

LxWxH

TM160HD :150x130x35mm / TM190HD : 150x130x35mm

• audio : AAC - MPEG1-L2

Weight

0.6 kg

EAN code

TM160HD

5420037691609

• DVBT

TM190HD

5420037691906

TM190HD

The TM190HD is a HD encoder. The video and audio are taken from

HDMI.

Through an extra USB port it is possible to record your HDMI

source on a USB 3.0 stick. The content is saved as a .ts file. This .ts

(or other .ts files) can be played over the DVBT network, through

your modulator.

In order to facilitate the creation of .ts files, we have prepared a

special software called TS convertor. This software, available on

our website allows to convert .avi or .mp4 files to .ts, appropriate

for usage on our modulators and headends.

Standalone configuration is made easy through 4 tact switches and

ergonomic menu’s. To make the configuration of the TM190HD ul-

• USB function record and play

tra simple, a special software TMHDIface is available.

• video : H264

• audio : AAC - MPEG1-L2

• DVBT

HD ENCODER/MODULATOR

TM200HD

The TM200HD is a HD encoder. The video and audio are taken

Video input

Input

HDMI

from HDMI. It has additionnaly a bypass HDMI port.

Resolution modes

480p -576p -720p - 1080i -1080p

Compression

H.264 - bitrate 5-15 Mb/s

Through an USB port it is possible to record your HDMI

Audio input

Input

HDMI

source on a USB stick. The content is saved as .ts file. This

Sample Rate

HDMI (32kHz / 44.1 kHz / 48 kHz)

.ts (or other .ts files) can be played over the DVBT network,

Compression

AAC-LC or MPEG1-L2 - bitrate 128-384 Kb/s

through your modulator.

DVB Processing

Table insertion

PAT, PMT, SDT, NIT

Configuration

Channel/network name, SID, LCN, TSID, ONID, NID, audio, video PIDs…

Thanks to the on-board clock, it is possible to play/record

DVB-T output

Output frequency / level

170-230 MHz + 470-862 MHz / > 85 dBµV

your different .ts files according to a predefined time/date

Constellation - FEC

QPSK/16QAM/64QAM - 1/2, 2/3, 3/4, 5/6, 7/8

table.

Guard interval

1/4, 1/8, 1/16, 1/32

In order to facilitate the creation of .ts files, we have pre-

Mode - MER

2K/8K - 31 dB

pared a special software called TS convertor. This software,

Power

DC 2.1 mm connector

+5V

available on our website allows to convert .avi or .mp4 files to

Consumption

6 Watts

.ts, appropriate for usage on our modulators and headends.

Dimensions

LxWxH

150x130x35mm

Weight

0.6 kg

Furthermore, the TM200HD is equipped with an IR port al-

EAN code

TM200HD

5420037692002

lowing remote control of the HDMI source over the coaxial

cable. (ASK modulation only)

• HDMI Bypass

Standalone configuration is made easy through 4 tact switch-

• USB function record and play

es and ergonomic menu’s. To make the configuration of the

• Real ‘digital signage’ due to on board clock allowing distribution of different .ts file

TM200HD ultra simple, a special software TMHDIface is avail-

according to time/date table

TM2HD

able.

• Integrated IR transmitter

• Dual input HD encoder - DVBT modulator

• DVBT

•

1 single output DVBT channel

• USB function record and play for one HDMI input

• Real ‘digital signage’ due to on board clock allowing

distribution of different .ts files according to time/date

table

HD ENCODER/MODULATOR

TM220HD

Technical specifications

The TM220HD is a HD encoder, the video input can be taken from

TM250HD

TM220HD

Video inputs

Input

HDMI - YUV - Computer analog input HDMI

HDMI. The audio can be taken from HDMI or analog audio.

Resolution modes

480p -576p -720p - 1080i - VGA -

480p -576p -720p - 1080i

SVGA - XGA - SXGA

After compressing the video into H264 or MPEG2 and audio in

Compression

H.264 or MPEG2 - bitrate 5-15 Mb/s

AAC, or MPEG1-L2 the output can be configured as DVB-T or DVB-C

Audio inputs

Input

HDMI - L/R analog audio input

modulator.

Sample Rate

HDMI (32kHz / 44.1 kHz / 48 kHz) - Analog (48 kHz)

Compression

AAC-LC or MPEG1-L2- bitrate 128-384 Kb/s

Standalone configuration is made easy through 4 tact switches and

DVB Processing

Table insertion

PAT, PMT, SDT, NIT

Configuration

Channel/network name, SID, LCN, TSID, ONID, NID, versions, audio,

ergonomic menu’s. To make the configuration of the TM220HD ul-

video PIDs…

tra simple, a special software TMHDIface is available.

DVB-T output

Output frequency

170-230 MHz + 470-862 MHz / > 80 dBµV

/ level

Constellation - FEC

QPSK/16QAM/64QAM - 1/2, 2/3, 3/4, 5/6, 7/8

Guard interval

1/4, 1/8, 1/16, 1/32

Mode - MER

2K/8K - 35 dB

DVB-C output

Output frequency

50-862 MHz / > 80 dBµV

/ level

Constellation - Sym-

16, 32, 64, 128, 256 QAM (EN 300 429) - 4,00 - 6,96 Msps

bolrate

IP streaming

Interface

10/100 Base-T

• video : H264, MPEG2

Streaming

UDP/RTP...

Power

DC 2.1 mm connector

+5V

• audio : AAC - MPEG1-L2

Consumption

10 Watts

Dimensions

L x W x H

170x130x35mm

• DVBT, DVBC

Weight

0.6 kg

EAN code

54200376992552

54200376992200

TM250HD

The TM250HD is a HD encoder, the video input can be taken from

HDMI, PC or Component Video. The audio can be taken from HDMI

TMHDIface

or analog audio.

After compressing the video into H264 or MPEG2 and audio in

AAC, or MPEG1-L2 the output can be configured as DVB-T, DVB-C

modulator or as IP streamer.

Standalone configuration is made easy through 4 tact switches and

ergonomic menu’s. To make the configuration of the TM250HD ul-

tra simple, a special software TMHDIface is available.

• video : H264, MPEG2

• audio : AAC - MPEG1-L2

• DVBT,DVBC, IP

HD ENCODER/MODULATOR

TM4HDV

Technical specifications

The TM4HDV encoder/ modulator allows to encode

Video inputs

Inputs x 4

HDMI

up to 4 HDMI sources and this with a resolution of

Resolutions

720p - 1080P (1080i)

up 1080P for each input.

Compression

H.264 - bitrate 5-15 Mb/s

Audio inputs

Inputs

HDMI

The 4 sources are then available in DVBT or DVBC at

Sampling rate

HDMI (32kHz / 44.1 kHz / 48 kHz)

the output on 3 or 4 adjacent channels.

Compression

AAC-LC / MPEG1-L2 -symbol rate 128-384 Kb/s

DVB processing

Table Insertion

PAT, PMT, SDT, NIT, EIT

The TM4HDV is wall mountable.

Configuration

Program/network name , SID, LCN, TSID, ONID, NID, EIT,

versions, audio, video PIDs…

DVB-T output

Frequency/level

170-230 MHz + 470-862 MHz / > 95dBµV

3 adjacent channels

Constellation - FEC

QPSK/16QAM/64QAM - 1/2, 2/3, 3/4, 5/6, 7/8

Guard Interval

1/4, 1/8, 1/16, 1/32

Mode - MER

2K/8K - 35 dB

DVB-C output*

Frequency level

50-862 MHz / > 95 dBµV

4 adjacent channels

Constellation -

16, 32, 64, 128, 256 QAM (EN 300 429) - 4,00 - 6,96 Msps

Symbol rate

Power

DC - 2.1 mm -

+5V

connector

Consumption

17 Watts

Dimensions

LxWxH

200x135x67mm

Weight

0.6 kg

TM4HD

EAN code

TM4HD

5420037692569

TM4HDV

5420037692576

The TM4HD encoder/ modulator allows

to encode up to 4 HDMI sources and this

with a resolution of up 1080P for each

input.

The 4 sources are then available in DVBT

TM4HD with 19 inch brackets mounted. Backpanel in front.

or DVBC at the output on 3 or 4 adjacent

channels.

The TM4HD is a desktop model or can be

mounted in an 19 inch rack by fixing the

included brackets.

TM4HD with 19 inch brackets mounted. Frontpanel in front.

A/V ENCODER/MODULATOR

TM250

TM250 is an A/V to DVBT modulator. It accepts a video source

Technical specifications

(CVBS) , encodes it in an MPEG2-SD, MPEG2 or H264 and modu-

lates it in DVBT format.

Input

Video

CVBS

Programming of the modulator is easy using

4 tact switches on

Video input level

0.7

1.4 Vpp

the front of the modulator together with the LCD display. Another

Impedance

75 ohm

Standards

PAL / NTSC

option, is to program it by PC using the interface TMIface.

Audio input

0.5 - 2.5 Vpp

Compression Video

MPEG2-SD, MPEG2, H.264

Bitrate video

12 MBit/s

TMIface

Audio

MPEG1, Layer II

Bitrate audio

128, 192, 256, 320, 384 Kbit/s

DVB Processing Insertion of tables

PAT, PMT, SDT, NIT

Configuration

Channel Name, SID, LCN, NID, Network Name, TSID, ONID, LCN

Output

DVBT

Carriers - Bandwidth - MER

2K/8K - 6/7/8 MHz - 31dB

Frequency - Output level

47-862 MHz > 85 dBµV (adjustable 0 / -19 dB)

Bypass loss

< 2 dB

Adaptor

Input // Output

100 - 240V / 0.5A / 50-60Hz // 5V - 2A

Consumption of TM250

6 W

Dimensions

LxWxH

160x110x35mm

Weight

0.5 kg

EAN code

TM250

5420037692507

TM300

TM400

The TM300 and TM400 are audio - video encoders with multiple inputs.

They allow to encode 2 (TM300) or 4 (TM400) audio video sources in MPEG2 and

to remodulate them into DVBT.

One DVBT channel is available at the output in order to remodulate the 2 or 4

MPEG2 streams coming from the encoders.

A high DVBT output level makes it possible to feed large distribution networks

without additional amplification.

TM300 - TM400 :

the ideal compact solution for distributing audio video sources

over a DVBT network.

-> event programs in hotels and guest houses.

-> digital TV programs via DVB receiver

-> information channels in large CATV systems

A/V ENCODER/MODULATOR

CM300

Input (x2) for TM300/CM300

Video - level

CVBS - 0.7

1.4Vpp

The CM300 and CM400 are audio - video encoders with multiple

(x4) for TM400/CM400

inputs.

Impedance

75 Ohms

Audio

0.5...2.5 Vpp

They allow to encode 2 (CM300) or 4 (CM400) audio video sources

Compression

Video - bitrate

MPEG2 - 4

12 Mb/s

in MPEG2 and to remodulate them into DVBC or DVBT.

Audio - bitrate

MPEG1, Layer II - 128, 192, 256, 320, 384 kb/s

DVBT output (3 adjac. channels*)

Maximum output

> 95 dBµV

Four adjacent DVBC or three adjacent DVBT channels are available

(TM300/TM400 - 1 DVBT channel only)

Attenuation

1 - 20dB (using DTVIface)

DVBC output (4 adjac. channels)

Insertion loss

< 2 dB

at the output in order to remodulate the 2 or 4 MPEG2 streams

DVBT

DVBC

coming from the encoders.

Output frequency

170-230 MHz + 470-862 MHz

50-862 MHz

Constellation

QPSK/16QAM/64QAM

16,32,64,128,256 QAM

The modulator can be reconfigured in the field to be DVBC or DVBT.

FEC

1/2, 2/3, 3/4, 5/6, 7/8

Guard interval

1/4, 1/8, 1/16, 1/32

A high DVBC/T output level makes it possible to feed large distribu-

Mode - MER

2K - 35 dB (CM300/CM400)

- > 39 dB

2K/8K - 31 dB (TM300/TM400)

tion networks without additional amplification.

DVB Processing

Program Name, Service ID, TsID, NIT version, ONID, NID,

Network Name, LCN

Adaptor

Input - output

100-240 VAC / 50-60Hz - +5V - 4A

CM300 - CM400 :

Dimensions

Length x Height

181mm x 103 mm

the ideal compact solution for distributing audio video

Width

CM300 = 68mm - CM400 = 95mm

Weight

CM300 = 1.5 kg - CM400 = 1.6 kg

sources over a DVBT/C network.

EAN code

CM300

5420037692538

-> event programs in hotels and guest houses.

CM400

5420037692545

TM300

5420037692514

-> digital TV programs via DVB receiver

TM400

5420037692521

-> information channels in large CATV systems

CM400

By pressing the T<->C button in DTVIface, the DVBC

DTVIface - CM400

modulator can be converted in DVBT or vice versa.

(CM300 and CM400 only).

Masthead amplifiers : LTE compatible - 4G and 5G

A282

• High UHF gain

• Interstage attenuators result in low noise figure in all conditions

• All UHF inputs are equipped with a very steep low pass filter in

order to highly reject the ingress from LTE (4G or 5G) signals

• All amplifiers shielded and with F connectors

• Weatherproof outdoor housing in HIPS.

• Protected against atmospheric discharges.

Each UHF input equipped with very steep

low pass filter

A272

A282

A292

A295

A409

A376

A362

Ref.

0272

0282

0292

0295

0409

0376

0362

HF inputs

Frequency bands (channels)

21-60

21-49

BIII(DAB)/21-60

21-60/21-60

Nominal gain (dB)

20*

28*

38*

20* / 28*

28* / 38*

36* / 36*

Noise figure (dB)

< 5

< 3.5 / < 5

< 5 / < 5

Output level (dBµV)

105

Supply voltage **(Vdc)

5-24

Current consumption (mA)

< 40

< 60

< 70

< 60

Dimensions (mm)

125 x 110 x 50

125x110x50

125 x 110 x 50

Weight (kg)

0.2

EAN code

5420037602728

5420037602827

5420037602926

542003762955

5420037604098

5420037603763

5420037603626

besides the gain, indicates that gain is adjustable. This is typically 20 dB for the VHF inputs and 15 dB for the UHF inputs.

All amplifiers are fed by the coaxial cable connected to the output. The power supply A005 is advised to be used for these amplifiers.

A376

LTE block filter - 4G and 5G

Technical specifications - 4G

Pass band

1 - 790 MHz (channel 60 / canal 60)

Insertion loss

< 1 dB (5-700 MHz ), 3.5 dB typ. (700-790 MHz)

Stop band

814 - 1000 MHz

Rejection

> 50 dB

Cross band

790-814 MHz

Order code / EAN code

F782

5420037637829

Technical specifications - 5G

Pass band

1 - 694 MHz (channel 49 / canal 49)

Insertion loss

< 1 dB (5-700 MHz ), 3.5 dB typ. (700-790 MHz)

Stop band

714- 1000 MHz

Rejection

> 50 dB

Cross band

694-714 MHz

Order code / EAN code

F694

5420037636946

LTE blockfilters / filtres LTE :

•

Block filters for elimination of the impact of harmful interferences from LTE (4G/5G) base stations at DVB-T devices.

•

Weatherproof housing.

•

Very low crossing bandwidth, very high rejection and low insertion loss

•

Excellent return loss / high screening.

Power supplies for mastheadamplifier

• Range with F connectors

• 1 or 2 outputs

• 24V and 12 or 24V through jumper

• Zamac splitter housing

• LED indication

• Invisible wall mounting

A005

A015

A020

Application

A056

Ref

Number of outputs

Insertion loss

Isolation

Max. current

Output voltage

Weight (kg)

EAN code

A005

< 4 dB

> 20 dB

100 mA

5V minimum

0.25

5420037600052

A015

< 4 dB

> 20 dB

45 mA

24 V

0.29

5420037600151

A020

< 1 dB

100 mA

24 V

0.34

5420037600205

A021

< 1 dB

100 mA

12 ou/or 24 V

0.34

5420037600212

A045

< 4 dB

> 20 dB

100 mA

24 V

0.34

5420037600458

A056

< 4 dB

> 20 dB

100 mA

12 ou/or 24 V

0.34

5420037600564

12 ou 24V

A021

A045

LED

Indoor distribution amplifier

Range

• A216 : VU - 2 outputs - 18 dB adjustable gain

A230

A225

• A217 : VU + return path - 2 outputs - 18 dB adjustable gain

• A225 : VU - 2 outputs - gain 25 dB (VHF and UHF adj. separately)

• A227 : VU - 2 outputs - gain 25 dB (VHF and UHF adj. separately) - with SAW LTE filter

• A411 : VU - 4 outputs - gain 12 dB (adjustable 2x2 outputs)

• A230 : VU + SAT - 2 outputs - gain terr. 28 dB / SAT 25 dB (gains separetely adjustable)

A217

A411

A227

Wall mounting

A216

Technical specifications

Reference

A216

A217

A225

A227

A411

A230

Outputs

Frequency

45-862 MHz

85-862 MHz

45-350 MHz/

45-862 MHz

45-790 MHz/

VR : 5-65 MHz

470-862 MHz

470-788 MHz

950-2150MHz

(integrated SAW filter)

Gain

5 - 18 dB

VHF : 5-25 dB

0 - 12 dB

Terr: 13 - 28 dB

UHF : 5-25 dB

UHF : 5-24 dB

(1 adjustement per 2

SAT : 15 - 25 dB

outputs)

Return path loss

6 dB

Noise figure

4,5 dB

Max. output level

105 dBµV

Input/Output return loss

> 10 dB

• Modern design

Isolation betw.outputs

> 20 dB

Power

230V / 4VA

• Power LED

Dimensions (mm)

95 x 115 x 35

Weight (kg)

0,30

0,31

0,34

0,33

• Easy wall mounting

EAN code

5420037602162

5420037602179

5420037602254

5420037602278

5420037604111

5420037602308

Multiband and CATV amplifiers

The multiband amplifiers and CATV amplifiers have been espe-

cially designed for the use in SMATV systems for the reception

of digital and analogue channels. Realised in zinc diecast hous-

ing, they utilise the latest development of transistors (GaAs-

MMIC). This results in products of small dimensions, low pow-

er consumption but caracterised with high linearity and high

output level.

A116

A118

A181

A113

A124

Technical specifications

A113

A116

A118

A181

A124

Number of inputs

(BI+FM/BIII/UHF)

(BI+FM/BIII/UHF/UHF)

(BI+FM/BIII/21-60/21-60)

(85-862 MHz)

(integrated SAW filter)

return path : 5-65 MHz

Number of outputs

Test output

yes : -30 dB

Gain (dB)

18/28/35

28/40/40/40

Gain return path (dB)

Slope adjustment (forward path (dB))

Attenuation range (each input) (dB)

0 - 18 dB

Noise figure (dB)

< 7 dB

Input/output return loss (dB)

> 10 dB

Max. output level

118

(IM3 : -52 dB : 3 equal carriers) (dBµV)

Remote power (activated by internal jumper)

5V / 200 mA

Voltage

230 Vac (-10%,+15%)

Power consumption (W)

Dimensions (mm)/weight (kg)

170 x 95 x 50 / 0.8

Code EAN

5420037601134

5420037601165

5420037601813

5420037601240

TV/SAT combiners

• TV/SAT combiner for TWIN LNB

C502

• Small outline

• High isolation

• Zamac housing

• Weatherproof housing

• High isolation

C504

• Small outline

C505

Specifications

C501

C502

C503

C505

C504

Frequency range (SAT)

950 - 2150 MHz

2 x 950-2150 MHz

Frequency range (terr.)

5-862 MHz

2 x 5-790 MHz

DC pass (terr./SAT)

non - no / oui - yes

Insertion loss (SAT)

< 3 dB

Insertion loss (terrestrial)

< 2 dB

< 5.5 dB

Isolation (SAT/terr)

> 40 dB

> 30 dB

> 40 dB

Isolation (terr/SAT)

> 30 dB

> 18 dB

> 30 dB

Code

1501

1502

1503

1505

1504

EAN code

5420037615018

5420037615025

5420037615032

5420037615056

5420037615049

Weight

0.080

0.18

0.052

0.18

0.20

• High isolation

• Zamac housing

Wideband splitter

Specifications

R822

R823

R824

Frequency range

5 - 2150 MHz

Number of outputs

DC pass all outputs

diode protection

Insertion loss (5-862)

< 4 dB

1 x < 4 dB / 2 x <8 dB

< 8 dB

Insertion loss (950-2150)

< 6 dB

1 x < 5 dB / 2 x <10 dB

< 10 dB

Code

7822

7823

7824

EAN code

5420037678228

5420037678235

5420037678242

Weight

0.14

0.15

DiSEqC switches

References

•

S152 :

2 inputs - 1 output

S152

S154

S153

S156

Frequency range (SAT)

950 - 2150 MHz

•

S154 :

4 inputs - 1 output

Satellite inputs

Frequency range (terrestrial)

40-862 MHz

•

S153 :

2 SAT inputs + 1 input terr - 1 output

Insertion loss (satellite)

< 3 dB

< 4 dB

Insertion loss (terrestrial)

< 2 dB

•

S156 :

3 SAT inputs + 1 input terr - 1 output

Isolation (SAT/SAT)

> 30 dB

> 25 dB

Isolation (SAT/terr)

> 40 dB

Switching control

Tone Burst

SAT A/B/C/D

SAT A/B/C

SAT A/B

Current

35 mA max.

DC loss

< 0.4 V

Current pass

500 mA max.

• DiSEqC 1.0

EAN code

5420037681525

5420037681549

5420037681532

5420037681563

• High isolation

• Short circuit proof

• Weatherproof housing

Satellite line amplifier

A921

A931

A945

Frequency range (SAT)

950 - 2150 MHz

Frequency range (terr.)

5-790 MHz

Insertion gain (SAT)

14...18 dB

20 dB

20...26 dB

Insertion gain (terrestrial)

20 dB

Gain control

terr : 15 dB/SAT : 20 dB

Max. output level (terr) (1)

108 dBµV

Max. output level (SAT) (2)

110 dBµV

116 dBµV

EAN code

5420037609215

5420037609314

5420037609451

Multiswitches 5 / 9 inputs

Technical specifications

M504

M506

M508

M512

M516

Number of satellite inputs

Number of receiver outputs

Frequency range (SAT)

950-2150 MHz

Frequency range (terr.)

5-862 MHz

Integrated terrestrial amplifier

Insertion loss (SAT)

-2

2 dB

Terrestrial gain (terrestrial amplifier ON)

8 dB

6 dB

5 dB

(switchable on/off by strap).

Insertion loss (terrestrial - amplifier OFF)

12 dB

15 dB

16 dB

15 dB

19 dB

Isolation (SAT/SAT)

> 30 dB

Isolation (SAT/terr)

> 40 dB

Isolation (Rx/Rx)

> 22 dB

Switching control

13V/18V/22kHz

Max. output level (SAT)

86 dBµV

Supplied with its separate power

Current (per rec.)

60mA max.

Dimensions

45x145x210mm

45x145x255mm

45x145x210mm

45x145x255mm

supply

EAN code

5420037665044

5420037665068

5420037665082

5420037665129

5420037665167

(ref : AG2418 : 18V - 1.0A)

On every receiver output DiSEqC A/B can be

toggled using DIP switch.

Integrated terrestrial amplifier

(switchable on/off by strap).

M904

M906

M908

M912

Number of satellite inputs

Number of receiver outputs

Frequency (satellite)

950-2150 MHz

Frequency (terrestrial)

5-862 MHz

Insertion gain (SAT)

-3...1 dB

-4...0 dB

-6...-2 dB

Terrestrial gain (terrestrial amplifier ON)

8 dB

5 dB

4 dB

0 dB

Insertion loss (terrestrial - amplifier OFF)

12 dB

15 dB

16 dB

Isolation (Sat/terr)

> 40 dB

Isolation (terr/sat)

> 20 dB

Isolation (sat/sat)

> 26 dB

Isolation (rx/rx)

> 24 dB

Supplied with its separate power

Max. output level (SAT)

86 dBµV

supply

Switching control

13V/18V/22kHz + DiSEqC 2.0

(ref : AG2414 : 14V - 1.7A)

Dimensions

180x210x46mm

220x210x46mm

330x210x46mm

EAN code

5420037669042

5420037669066

5420037669080

5420037669127

Quattro SAT IF amplifier

Technical specifications

M402

A404

Number of satellite inputs

Frequency range

950-2150 MHz

Satellite gain (sloped)

22...28 dB

10...15 dB

Gain control

20 dB

Isolation trunk/trunk

> 32

Power supply

14 V/1.7 A (incl.)

Max. output level SAT (IM3 - 35 dB)

120 dBµV

Power consumption

8 W

Dimensions

130x90x45 mm

EAN code

5420037664023

5420037604043

Cascadable multiswitches - 5 inputs

Reference

M541

M542

M543

M544 terminal

• Cascadable multiswitch with different tap values

Insertion loss - trunk lines (terrestrial)

5,5 dB

3,5 dB

2,5 dB

• Terrestrial passive 5-862 MHz

Insertion loss - trunk lines (satellite)

< 3 dB

Tap loss (terrestrial)

14 dB typ.

18 dB typ.

21 dB typ.

11 dB typ.

• 4 IF switching with terrestrial combiner at each outlet

Tap loss (satellite)

7...3 dB

8 dB

13 dB

+2 dB

• DC pass on satellite trunk line

EAN code

5420037665419

5420037665426

5420037665433

Number of satellite inputs

Reference

M561

M562

M563

M564 terminal

Frequency range (sat)

950-2150 MHz

Insertion loss - trunk lines (terrestrial)

5,5 dB

3,5 dB

2,5 dB

Frequency range (terrestrial)

5-862 MHz

Insertion loss - trunk lines (satellite)

< 3 dB

Isolation (trunk/trunk)

> 32 dB

Tap loss (terrestrial)

16 dB typ.

20 dB typ.

23 dB typ.

13 dB typ.

Isolation (sat/terr)

> 40 dB

Tap loss (satellite)

3 dB

8 dB

13 dB

+2 dB

Isolation (sat/sat)

> 26 dB

EAN code

5420037665617

5420037665624

5420037665631

5420037665648

Isolation (rx/rx)

> 24 dB

Max. output level (SAT)

86 dBµV

Switching control

13V/18V/22kHz

Reference

M581

M582

M583

M584 terminal

Current per outlet

< 60 mA

Insertion loss - trunk lines (terrestrial)

5,5 dB

3,5 dB

2,5 dB

Dimensions (mm)

130 x 210 x 45 mm (M54x, M56x)

Insertion loss - trunk lines (satellite)

< 4 dB

130 x 255 x 45 mm (M58x)

Tap loss (terrestrial)

18 dB typ.

22 dB typ.

25 dB typ.

14 dB typ.

Tap loss (satellite)

3 dB

8 dB

17...13 dB

0...+5 dB

EAN code

5420037665815

5420037665822

5420037665839

5420037665846

Cascadable multiswitches - 9 inputs

Number of satellite inputs

Frequency range (sat)

950-2150 MHz

Frequency range (terrestrial)

5-862 MHz

• Multiswitch with 9 inputs, 9 outputs and 4,6 or 8 receiver outlets

Isolation (trunk/trunk)

> 32 dB

• Cascadable multiswitch with different tap values

Isolation (sat/terr)

> 40 dB

• Terrestrial passive 5-862 MHz

Isolation (sat/sat)

> 26 dB

Isolation (rx/rx)

> 24 dB

• 8 IF switching with terrestrial combiner at each outlet

Max. output level (SAT) (tap

86 dBµV

• Group A or B with or without DiSEqC

outputs)

Switching control

13V/18V/22kHz + DiSEqC 2.0

• DC pass on satellite trunk lines

Current per outlet

< 60 mA

• Integrated power inserter

Dimensions (mm)

206 x 184 x 46 mm (M94x, M96x)

206 x 223 x 46 mm (M98x)

Reference

M941

M942

M943

M944 terminal

Insertion loss - trunk lines (terr)

5,5 dB

3,5 dB

2,5 dB

Insertion loss - trunk lines (sat)

< 3 dB

Tap loss (terrestrial)

14 dB typ.

18 dB typ.

21 dB typ.

10 dB typ.

Tap loss (satellite)

7 dB

11 dB

16 dB

0 dB

EAN code

5420037669417

5420037669424

5420037669431

5420037669448

Reference

M961

M962

M963

M964 terminal

Insertion loss - trunk lines (terr)

5,5 dB

3,5 dB

2,5 dB

Insertion loss - trunk lines (sat)

< 3 dB

Tap loss (terrestrial)

15 dB typ.

19 dB typ.

22 dB typ.

12 dB typ.

Tap loss (satellite)

7 dB

11 dB

16 dB

0 dB

EAN code

5420037669615

5420037669622

5420037669639

5420037669646

Reference

M981

M982

M983

M984 terminal

Insertion loss - trunk lines (terr)

5,5 dB

3,5 dB

2,5 dB

Insertion loss - trunk lines (sat)

< 4 dB

Tap loss (terrestrial)

17 dB typ.

21 dB typ.

24 dB typ.

14 dB typ.

Tap loss (satellite)

7 dB

11 dB

16 dB

0 dB

EAN code

5420037669813

5420037669820

5420037669837

5420037669844

Quattro SAT IF splitter

R428

R418

Number of satellite inputs

Number of satellite outputs

Frequency range

950-2150 MHz

Insertion loss

5 dB

1 dB

Tap loss

5 dB

11 dB

Power pass

500 mA (2 out)

500 mA (1 out)

Dimensions

130x90x45 mm

EAN code

5420037664023

5420037604043
